B25 Metallic Pump

  • Material options suitable for a wide range of applications
  • Simple construction, easy to maintain
  • Self-priming, ideal for emptying containers
  • End ported for improved flow
  • Pressures to 8.6 bar (125 PSI)
  • Flow rates up to 180 litres/minute (48 gal/min)
  • Bolted construction for greater integrity
  • Weighted valve balls for high S.G. and viscous fluids
  • Reliable pneumatic air valve

Interested in our products? Connect with us easily! Simply scan the QR code or click the link to reach us on Line. We’re here to help with any questions or orders!

QR Code
Category:

Specifications

  • Maximum Delivery 180 ltrs/min (48 gal/min)
  • Max. Working Pressure 8.6 bar (125 PSI)
  • Max. Solid Particle Size 3 mm. (0.12″)
  • Air Inlet 3/8″ NPT
  • Temperature Limits Determined by Elastomers
  • Suction Lift (Dry) 6.1 metres (20 feet)
  • Suction Lift (Wet) 7.6 metres (24.9 feet)
  • Fluid Inlet / Outlet 1″ BSP / NPT
  • Installation Wall or Surface mounted
  • Accessories Included Exhaust Air Silencer
  • Shipping Weight
    16 kg. (35.3 lbs) aluminum
    25 kg. (55.1 lbs) cast iron/aluminum
    25 kg. (55.1 lbs) stainless steel/aluminum
  • Shipping Dimensions
    400 x 300 x 470 mm
    15.8″ x 11.8″ x 18.5″
