ATEX ZONE 2 – ZONE 22
II 3G Ex h IIB T4 Gc
II 3D Ex h IIIB T135°C Dc X
ZONE 1 – ZONE 21
II 2G Ex h IIB T4 Gb
II 2D Ex h IIIB T135°C Db X
Technical Specification
Head / Flow rate guaranteed in compliance with ISO 9906
| Suction/delivery connections | BSPP 1/4″ f (*) |
| Air fitting | BSPP 1/8” f |
| Max flow rate | 6 l/min |
| Max supply air pressure | 8 bar |
| Max negative suction head – dry-running ** | 3 m |
| Max negative suction head – pump primed | 9,5 m |
| Diameter max suspended solids | 0 mm |
| Noise level | 60 dB |
| Volume stroke | 3,2 cc |
(*) NPT fittings on request
PLASTIC MATERIAL PP (GF/GF)
| Version | Weight | Min | Max |
| PP (with glass additive) | 0,4 kg | 3° C | 65° C |
| PP conductive (with carbo additive) | 0,4 kg | 3° C | 65° C |
| Maximum dimensions | Plastic |
| Height | 75 mm |
| Width | 86 mm |
| Depth | 60 mm |
